TEARDOWNSTN 00 / 06
OKTET OS-2400
OKTET · NETWORK HARDWARE · EST. 192.168
Infrastructure,to spec.
Managed switches, routers and access points built like instruments — every port measured, every spec published, every unit burned-in before it ships.
LINK ···
01 / WHY OKTET
Built like instruments, documented like datasheets.
No marketing throughput. No asterisks. Every number on this site is the number you measure on the bench — published in full, line-rate, both directions.
48HRS
Every switch runs a 48-hour thermal and traffic soak before it leaves the line. If a unit drifts, it never ships.
FABRIC
2.16TBPS
OS-4800 SWITCHING FABRIC
CERTIFICATION
- UL 62368-1
- IEC / EN 62368
- CE · UKCA · FCC B
- RoHS 3 · REACH
“We publish the failure rate, the MTBF method, and the test rig. If you can’t repeat our numbers, that’s a bug — and we want the ticket.”
— OKTET HARDWARE RELIABILITYRELIABILITY
200kHRS
MTBF · TELCORDIA SR-332
02 / HARDWARE
All products →The line, end to end.
OKTET OS-2400
Twenty-four ports of line-rate 10GbE, four 25G uplinks, no oversubscription.
- Ports
- 24× SFP+ 10GbE · 4× SFP28 25GbE
- Switching capacity
- 680 Gbps / 506 Mpps
- Management
- L3 lite · CLI · REST · SNMP
From $1,290→
OKTET OS-4800
Forty-eight 10GbE ports and six 100G uplinks for the aggregation layer.
- Ports
- 48× SFP+ 10GbE · 6× QSFP28 100GbE
- Switching capacity
- 2.16 Tbps / 1,607 Mpps
- Management
- Full L3 · BGP · CLI · REST
From $3,480→
OKTET OP-1600
Sixteen PoE++ ports, a 740W budget, and the headroom to spend it honestly.
- Ports
- 16× RJ45 2.5GbE PoE++ · 2× SFP+ uplink
- PoE budget
- 740 W total (IEEE 802.3bt Type 4)
- Per-port
- Up to 90 W (Class 8)
From $980→
OKTET OR-8000
Enterprise edge routing and stateful firewall at 40 Gbps, line-rate where it counts.
- Throughput
- 40 Gbps firewall · 28 Gbps IPsec VPN
- Ports
- 8× SFP+ 10GbE · 2× RJ45 2.5GbE
- Sessions
- 8,000,000 concurrent / 480k new/s
From $2,640→
TEARDOWN / OS-2400
Scroll to page through the spec →The OS-2400, to the octet.
ACCESS LAYERSTN 01 / 06
24 × SFP+ 10GbE
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
Line-rate on every port, both directions, 64-byte frames included. Mix SR / LR optics or DAC — the PHY is the same either way.
UPLINKSTN 02 / 06
4 × SFP28 25GbE
01
02
03
04
Twenty-five-gig uplinks into an OS-4800 spine. LACP for the simple path, EVPN-VXLAN when you outgrow it.
FABRICSTN 03 / 06
Non-blocking, measured
680GBPS
Switching capacity
506MPPS
Forwarding rate
32K
MAC table entries
16MB
Shared packet buffer
POWER & ENVSTN 04 / 06
Dual hot-swap PSU
| Power | 2× 250W, 1+1 hot-swap |
|---|---|
| Cooling | Front-to-back, dual fan |
| Operating temp | 0 – 45 °C |
| MTBF | > 220,000 hrs (SR-332) |
| Acoustic | < 42 dBA @ 25 °C |
MANAGEMENTSTN 05 / 06
OKTET-OS · CLI · API
| CLI | SSH, industry-standard syntax |
|---|---|
| API | REST + gNMI / gNOI |
| Provisioning | Zero-touch (ZTP) |
| Telemetry | Streaming, OpenConfig |
03 / SOLUTIONSSized for where
Sized for where
it actually runs.
The same hardware, specified four different ways — because a 40-cabinet row and a single wiring closet are not the same problem.
All deployment guides →01
Enterprise Campus
One switching fabric across every building, managed from one place, with no closet left behind.
ISP & WISP
Edge routing and aggregation that holds line rate under real subscriber load, not lab load.
Data Center
A non-blocking leaf-spine fabric you can cable once and grow into for years.
Small Business
Business-grade networking that fits one closet, one budget, and no full-time IT.
04 / FIELD RECORD
See deploymentsThe numbers, after the install.
0%
Measured uptime, 40-site fleet
0M
Ports shipped & burned-in
0
Countries deployed
0yr
Median hardware service life
READY WHEN YOU ARESpec your network
Spec your network
down to the octet.
Send us the floor plan, the port count, the uptime target. You’ll get a real bill of materials and a wiring plan back — not a sales call.
TYPICAL TURNAROUND / 2 BUSINESS DAYS · NDA ON REQUEST
