OS-2400
SKU OKT-OS2400 · From $1,290
Twenty-four ports of line-rate 10GbE, four 25G uplinks, no oversubscription.
- 680 Gbps non-blocking fabric — every port runs at line rate simultaneously.
- 4× 25G SFP28 uplinks for true 2.5:1 leaf-spine fan-in without oversubscription.
- Dual hot-swap 250W PSUs and 2+1 fans — no single point of failure in the chassis.
Ports
24× SFP+ 10GbE · 4× SFP28 25GbE
Switching capacity
680 Gbps / 506 Mpps
Management
L3 lite · CLI · REST · SNMP
PoE
None (SFP fiber/DAC)
Every number, published.
Interfaces
| Data ports | 24× SFP+ (10GbE / 1GbE) |
|---|---|
| Uplink ports | 4× SFP28 (25GbE / 10GbE) |
| Management port | 1× RJ45 10/100/1000 out-of-band |
| Console | 1× RJ45 RS-232, 1× USB-C |
| MAC address table | 288,000 entries |
| Jumbo frames | 9,216 bytes |
Performance
| Switching capacity | 680 Gbps non-blocking |
|---|---|
| Forwarding rate | 506 Mpps (64-byte packets) |
| Packet buffer | 16 MB shared |
| Latency | < 1.2 µs (cut-through, 64B) |
| VLANs | 4,094 (802.1Q) |
| Routing | Static, OSPFv2, ECMP, VRRP |
Power & Environment
| Power supplies | 2× 250W hot-swap (1+1 redundant) |
|---|---|
| Typical draw | 98 W (24 ports, DAC) |
| Cooling | 2+1 hot-swap fans, front-to-back |
| Operating temperature | 0 °C to 45 °C |
| MTBF | 342,000 hours (25 °C) |
| Form factor | 1U, 440 × 320 × 44 mm |
The front panel, to the octet.
Each interface is octet-numbered and colour-keyed by media. Hover a cell for its role.
- Fiber / SFP
- Copper / RJ45
- Console
Photographed as hardware.
The OS-2400 is the switch we built to be the core of a mid-size deployment without asking you to compromise. Twenty-four SFP+ ports and four SFP28 uplinks share a 680 Gbps fabric, which means the bandwidth math works out: 24 × 10G plus 4 × 25G is 340 Gbps of port capacity, and the fabric carries double that, full-duplex, with no internal oversubscription. We publish the forwarding rate at 64-byte packets — 506 Mpps — because that is the number that tells you how the switch behaves under small-packet load, not the number that looks best on a slide.
Management is the same surface whether you reach it over the serial console, the out-of-band RJ45, SSH, REST, or SNMP. Configuration applied through one path is visible and identical through the others; there is no hidden web-only state. Layer-3 is deliberately scoped — static routing, OSPFv2, ECMP, and VRRP cover the aggregation and small-core roles this box is sized for. If you need full BGP at the edge, that is the OR-8000’s job, and we will tell you so rather than overselling this one.
The chassis carries dual 250W hot-swap supplies in a 1+1 configuration and three fans in 2+1, all serviceable from the front without downing the switch. Airflow is front-to-back to match hot-aisle layouts. Rated MTBF is 342,000 hours at 25 °C; operating range is 0 °C to 45 °C inlet.
What’s in the box: OS-2400 chassis, two 250W PSUs, two C13 power cords (region-specific), one RJ45-to-DB9 console adapter, OC-RACKKIT-compatible mounting ears, and the quick-deploy card with default-credential and OOB-IP reset instructions. SFP/SFP28 optics and DAC cables are ordered separately — see OF-SFP10.
Spec it against the rest of the line.
Drop the OS-2400 into the Network Builder, or browse the full catalog.
